SA270MN SIRIO Dual-Band Fiberglass Hi Gain Base Station Antenna 2m And 70cm Bands 2103420.00
$93.99
Tax Excluded
Features:
Available version for USA ham band (146 & 445 MHz).
UPGRADE: new and strongest cylindrical fiberglass tube
Product Number:
| P/N: 2103420.00 | SA 270 MN |
Electrical Data:
| Type: | VHF: 6/8 λ UHF: 3 x 5/8 λ colinear |
| Radiation: | Omnidirectional |
| Polarization: | Linear vertical |
| Frequency range: | 142-148 MHz & 427-442 MHz No tuning required |
| Systems: | 2m-HAM, 70cm-HAM, ORBCOMM M2M, TETRA, CDMA-450, ISM/SIGFOX/LoRa 433MHz |
| Gain: | VHF: 2 dBd – 4.15 dBi UHF: 4.2 dBd – 6.35 dBi |
| Max Power: | 200W |
| Grounding protection: | All metal parts are DC-grounded, the inner conductor is coupled capacitively |
| Connector: | N-female |
Mechanical Data:
| Materials: | Aluminium, Chromed brass, Stainless steel, Fiberglass |
| Height (approx): | 1720 mm / 5.64 ft |
| Weight (approx): | 1030 gr / 2.27 lb |
| Mounting type: | On-Mast |
